Yd
Basic Info.
Model NO. | YD-5 3.2~4.6mm 55/45 |
Certification | ISO9001 |
Customized | Customized |
Material | Alloy |
Application | Metal Cutting Machine, Metal Processing Machinery Parts |
Welding Core Type | Carbide Particle |
Yg Particle Sizes | 3.2~4.8mm |
Length | 450mm or 290mm |
S221 Melting Temperature | 890-905 |
Usage | Surfacing Electrode, Low Hydrogen Type Electrode |
Cunizn | 45% |
Yg Particle % | 55% |
Function | Hardfacing Electrode |
Diameter | 11mm |
Welding Power | AC/DC |
Electrode Coating Type | Base |
Stainless Steel Welding Rod Type | Chromium Cooper Stainless Steel |
Type | Co(Cooper/Cooper-Alloy Welding Electrode) |
Transport Package | 25kg. Carton |
Specification | YD-5 3.2~4.8mm 55/45 |
Trademark | ZZUP |
Origin | Zhuzhou, Hunan, China |
HS Code | 820900100 |
Production Capacity | 10000kg/Month |
Packaging & Delivery
Package Size 17.00cm * 16.00cm * 10.00cm Package Gross Weight 1.500kgProduct Description
YD type hard alloy composite surfacing electrode (YD type electrode for short) is made by mixing granular sintered hard alloy and elastic carcass alloy. Coated with a layer of special flux and colored to identify the particle size. The sintered cemented carbide particles are mainly cobalt-containing tungsten carbide, with a hardness of HRA89-91; the matrix metal is a "nickel-copper" alloy, with a tensile strength of 690MPa, and hardness: HB≥ 160
1.carbide copper alloy brazing rod it is made of by sintering tungsten carbide scrap and elastic matrix alloy,Outer layer of the special flux and coloring is marking scrap grade,the composition of sintering tungsten carbide scrap is mainly CO and WC,The hardness is HRA 89~91,tire body matal is Ni and copper alloy,strength can up to 690MPa, hardness HB≥160.2.Common particle sizes :1/16" x 1/8" (1.6 x 3.2 mm) , 3/16" x 1/8" (3.2 x 4.8 mm) , 1/4" x 3/16" (4.8 x 6.4 mm) , 5/16" x 1/4" (6.4 x 7.9mm) , 3/8" x 5/16" (7.9 x 9.5 mm), 1/2" x 3/8" (9.5 x 12.7 mm).3.length :280mm ,450mm4. YG +CuSnZn or YG+CuSnZn+10% Ni5.WC grit compositions : 70% ,60%,50%
Product Name | Carbide Yd Welding Rod |
Material | tungsten carbide particle (55%) ,CuSnZn(45%) |
Color | yellow |
Brade | ZZUP |
YG particle size | 3.2~4.8mm |
Used | overlay the worn-out and cutting usage workpieces in oil,mining,coal mining,geology,contruction and other industries, such as :milling shoes,wear shoes,centralizers,reamer,drill pipe joints,hydraulic cutter,scrapper blade plow planer,drill core,piling drilling,auger etc |
